Lincoln Nautilus: Maintenance / Engine Oil

Lincoln Nautilus 2018-2025 Owners Manual / Maintenance / Engine Oil

Engine Oil Dipstick Overview - 2.0L

Lincoln Nautilus. Engine Oil

  1. Minimum.
  2. Nominal.
  3. Maximum.

Engine Oil Dipstick Overview - 2.7L

Lincoln Nautilus. Engine Oil

  1. Minimum.
  2. Nominal.
  3. Maximum.

Checking the Engine Oil Level

  1. Make sure that your vehicle is on level ground.
  2. Check the oil level before starting the engine, or switch the engine off after warming up and wait 10 minutes for the oil to drain into the oil pan.
  3. Remove the dipstick and wipe it with a clean, lint-free cloth.
  4. Reinstall the dipstick and make sure it is fully seated.
  5. Remove the dipstick again to check the oil level.

    Note: If the oil level is between the maximum and minimum marks, the oil level is acceptable. Do not add oil.

  6. If the oil level is at the minimum mark, immediately add oil.
  7. Reinstall the dipstick. Make sure it is fully seated.

    Note: The oil consumption of new engines reaches its normal level after approximately 3,000 mi (5,000 km).

Adding Engine Oil

WARNING: Do not remove the filler cap when the engine is running.

WARNING: Do not add engine oil when the engine is hot. Failure to follow this instruction could result in personal injury.

Do not use supplemental engine oil additives because they are unnecessary and could lead to engine damage that the vehicle warranty may not cover.

  1. Clean the area surrounding the engine oil filler cap before you remove it.
  2. Remove the engine oil filler cap.
  3. Add engine oil that meets our specifications. See Capacities and Specifications.
  4. Reinstall the engine oil filler cap. Turn it clockwise until you feel a strong resistance.

Note: Do not add oil further than the maximum mark. Oil levels above the maximum mark may cause engine damage.

Note: Immediately soak up any oil spillage with an absorbent cloth.

Resetting the Engine Oil Change Reminder

Use the information display controls on the steering wheel to reset the oil change indicator.

From the main menu scroll to:

Lincoln Nautilus. Engine Oil

Lincoln Nautilus. Engine Oil

Engine Oil Capacity and Specification

For filling information, please refer to the Capacities and Specifications section of your owner's manual. See Engine Oil Capacity and Specification.
